SXTsq Lite2

SXTsq Lite2

$54.56 CAD
SXTsq Lite2

SXTsq Lite2

RBSXTsq2nD
$54.56 CAD
Shipping calculated at checkout.
Out of stock

Low-cost small-size 10dBi 2.4GHz dual chain integrated CPE/Backbone.

The SXTsq Lite2 is a compact and lightweight outdoor wireless device with an integrated antenna. Perfect for point-to-point links or as a CPE unit. It is compact, weatherproof and easy to mount.

The SXTsq Lite2 retains a 10 dBi antenna like the SXT Lite2, our previous model, yet the antenna design has been improved and the physical size has been dramatically reduced - the SXTsq is two times thinner.
SXTsq Lite2
  • SXTsq Lite2
  • SXTsq Lite2
  • SXTsq Lite2

Specification

Specifications

  • Product codeRBSXTsq2nD
  • Suggested price$39.00
  • ArchitectureMIPSBE
  • CPUQCA9533
  • CPU core count1
  • CPU nominal frequency650 MHz
  • Dimensions129 x 129 x 34 mm
  • RouterOS license3
  • Operating SystemRouterOS
  • Size of RAM64 MB
  • Storage size16 MB
  • Storage typeFLASH
  • MTBFApproximately 100'000 hours at 25C
  • Tested ambient temperature-40°C to 70°C

Powering

  • Number of DC inputs1 (PoE-IN)
  • Max power consumption5 W
  • PoE inPassive PoE
  • Cooling typePassive
  • PoE in input Voltage10-30 V

Wireless specifications

  • Wireless 2.4 GHz Max data rate300 Mbit/s
  • Wireless 2.4 GHz Number of chains2
  • Wireless 2.4 GHz standards802.11b/g/n
  • Antenna gain dBi for 2.4 GHz10
  • Wireless 2.4 GHz chip modelQCA9533
  • Wireless 2.4 GHz generationWi-Fi 4

Ethernet

  • 10/100 Ethernet ports1

Certification & Approvals

  • CertificationCE, FCC, IC, EAC, ROHS
  • IPIP54

Included parts24V 0.38A power adapterMetal ring (one)PoE injectorNoteThe device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.
