SXT SA5 ac

SXT SA5 ac

$166.49 CAD
SXT SA5 ac

SXT SA5 ac

RBSXTG-5HPacD-SA
$166.49 CAD
Shipping calculated at checkout.
Out of stock

802.11ac up to 540Mbit, high output, wide beamwidth sector antenna

The new AC standard is here, with up to 866Mbit over the air datarate, 256-QAM modulation, and 80MHz channels. 802.11a/n/ac opens up new possibilities and speeds never possible before.

The SXT ac is a new member in our 802.11ac product lineup, currently two models are available — with regular 28 degree antenna, and the SA model with a 90 wide beam - width sector antenna. Also support 802.11a/n standard, Nstreme and Nv2 protocols and are compatible with all legacy RouterBOARD devices.
 Both devices come with Gigabit Ethernet.
SXT SA5 ac
  • SXT SA5 ac
  • SXT SA5 ac

New products are backwards compatible - for example, you can replace your 5GHz 802.11a/n legacy Access Point with new 802.11ac product and your existing customers will still be able to connect to it.

SXT install guide:

- RBSXTG-5HPacD-SAr2-US (USA) is factory locked for 5170-5250MHz and 5725-5835MHz frequencies. This lock can not be removed.

- RBSXTG-5HPacD-SAr2 (International) supports 5150MHz-5875MHz range (Specific frequency range can be limited by country regulations).

Specification

Specifications

  • Product codeRBSXTG-5HPacD-SA
  • Suggested price$119.00
  • ArchitectureMIPSBE
  • CPUQCA9557
  • CPU core count1
  • CPU nominal frequency720 MHz
  • RouterOS license4
  • Operating SystemRouterOS
  • Size of RAM128 MB
  • Storage size128 MB
  • Storage typeNAND
  • MTBFApproximately 200'000 hours at 25C
  • Tested ambient temperature-40°C to 70°C

Powering

  • Number of DC inputs1 (PoE-IN)
  • Supported Voltage15-60V
  • Max power consumption12 W
  • PoE in802.3af/at
  • Cooling typePassive
  • PoE in input Voltage12-57 V

Wireless specifications

  • Wireless 5 GHz Max data rate867 Mbit/s
  • Wireless 5 GHz Number of chains2
  • Wireless 5 GHz standards802.11a/n/ac
  • Antenna gain dBi for 5 GHz14
  • Wireless 5 GHz chip modelQCA9892
  • Wireless 5 GHz generationWi-Fi 5

Ethernet

  • 10/100/1000 Ethernet ports1

Peripherals

  • Number of USB ports1
  • USB Power ResetYes
  • USB slot typeUSB type A
  • Max USB current (A)1

Other

  • PCB temperature monitorYes
  • Voltage MonitorYes
  • BeeperYes

Certification & Approvals

  • CertificationCE, FCC, IC, EAC, ROHS
  • IPIP54

Included parts24V 0.8A power adapterMetal ring (one)Pole mounting bracketGigabit PoE injectorNoteThe device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.
