L009UiGS-2HaxD-IN

L009UiGS-2HaxD-IN

$180.48 CAD

L009UiGS-2HaxD-IN

L009UiGS-2HaxD-IN
$180.48 CAD
Shipping calculated at checkout.
Out of stock

L009 is more than just a router. This product line is up to 4 times faster than RB2011, it has a modern ARM CPU with container support, an innovative enclosure that allows mounting up to four routers in a single 1U space, more RAM, PoE, and 2.5G SFP support. This version comes with 2.4 GHz ax dual-chain wireless.

L009 features a powerful dual-core ARM CPU. It offers significant improvement when it comes to routing and filtering, complex firewall rules, IPsec hardware encryption, and various advanced RouterOS features. ARM CPU architecture provides significant advantages over older MIPS-based devices. Like using all the latest Linux Kernel features. Or implementing your own container projects. The combination of a modern ARM CPU and a full-sized USB port is perfect for running custom container projects. You could run a Pi-hole adblock on this router, for example. Or you could use the USB to add an LTE modem of your choice. Imagination is the real limit here.

L009 is up to 4 times faster than RB2011 in most cases and setups, from simple fast path routing to complex bridge filters. And L009 IPsec hardware encryption ensures lower CPU usage without measurable performance degradation compared to the regular driver. You can expect around 60-90 Mbps throughput using a 1400 byte packet size.

L009UiGS-2HaxD-IN

Specification

Specifications

  • Product codeL009UiGS-2HaxD-IN
  • Suggested price$129.00
  • ArchitectureARM 32bit
  • CPUIPQ-5018
  • CPU core count2
  • CPU nominal frequency800 MHz
  • CPU Threads count2
  • Switch chip model88E6190
  • RouterOS license5
  • Operating SystemRouterOS v7
  • Size of RAM512 MB
  • Storage size128 MB
  • Storage typeNAND
  • MTBFApproximately 200'000 hours at 25C
  • Tested ambient temperature-40°C to 70°C

Wireless capabilities

  • Wireless 2.4 GHz Max data rate574 Mbit/s
  • Wireless 2.4 GHz Number of chains2
  • Wireless 2.4 GHz standards802.11b/g/n/ax
  • Antenna gain dBi for 2.4 GHz4
  • Wireless 2.4 GHz chip modelIPQ-5018
  • Wireless 2.4 GHz generationWi-Fi 6
  • WiFi speedAX600

Ethernet

  • 10/100/1000 Ethernet ports8
  • Number of 1G Ethernet ports with PoE-out1

Fiber

  • SFP ports1 (2.5G supported)

Peripherals

  • Serial console portRJ45
  • Number of USB ports1
  • USB Power ResetYes
  • USB slot typeUSB 3.0 type A
  • Max USB current (A)1.5

Powering

  • Number of DC inputs2 (DC jack, PoE-IN)
  • DC jack input Voltage24-56 V
  • Max power consumption47 W
  • Max power consumption without attachments14 W
  • PoE in802.3af/at
  • Cooling typePassive
  • PoE in input Voltage24-56 V

PoE-out

  • PoE-out portsEther8
  • PoE outPassive PoE
  • Low voltage PoE-Out current limit1 A
  • High voltage PoE-Out current limit450 mA
  • Max total out (A)1.0 A

Certification & Approvals

  • CertificationCE, FCC, IC, EAC, ROHS
  • IP20

Other

  • Mode buttonYes

Included parts24V 1.5A power adapterHGO indoor antenna kitK-55 screw kitNoteThe device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.Wireless Specification
