CRS317-1G-16S+RM

CRS317-1G-16S+RM

$698.13 CAD
CRS317-1G-16S+RM

CRS317-1G-16S+RM

CRS317-1G-16S+RM
$698.13 CAD
Shipping calculated at checkout.
Out of stock

Smart Switch, 1 x Gigabit LAN, 16 x SFP+ cages, Dual Core 800MHz CPU, 1GB RAM, 1U rackmount passive cooling case, Dual Power Supplies.

The new Cloud Router Switch 317-1G-16S+RM is a rack-mountable manageable switch with Layer3 features, it has 16 SFP+ ports for high performance 10GbE connectivity and a 1GbE copper port for management.

CRS317-1G-16S+RM is powered by a next generation switching chip, giving you wire speed performance for all sixteen 10GbE ports with any Ethernet frame size. New features such as hardware-based Spanning Tree Protocol and Link Aggregation (LACP) provide enhanced protection and true professional performance for your demanding network.
CRS317-1G-16S+RM
  • CRS317-1G-16S+RM
  • CRS317-1G-16S+RM

Specification

Specifications

  • Product codeCRS317-1G-16S+RM
  • Suggested price$499.00
  • ArchitectureARM 32bit
  • CPU98DX8216
  • CPU core count2
  • CPU nominal frequency800 MHz
  • CPU Threads count2
  • Switch chip model98DX8216
  • Dimensions443 x 224 x 44 mm
  • RouterOS license6
  • Operating SystemRouterOS / SwitchOS
  • Size of RAM1 GB
  • Storage size16 MB
  • Storage typeFLASH
  • MTBFApproximately 200'000 hours at 25C
  • Tested ambient temperature-20°C to 60°C

Powering

  • Number of AC inputs2
  • AC input range100-240
  • Number of PSU slots2
  • Frequency (Hz)50-60
  • Max power consumption44 W
  • Cooling type2 fans

Ethernet

  • 10/100/1000 Ethernet ports1

Fiber

  • SFP+ ports16

Peripherals

  • Serial console portRJ45

Other

  • CPU temperature monitorYes
  • BeeperYes

Certification & Approvals

  • CertificationCE, EAC, ROHS

Included partsRack ears2x IEC cordsK10 screw kitNoteThe device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.
