CRS310-8G+2S+IN

CRS310-8G+2S+IN

$306.39 CAD
CRS310-8G+2S+IN

CRS310-8G+2S+IN

CRS310-8G+2S+IN
$306.39 CAD
Shipping calculated at checkout.
Out of stock

Take advantage of the blazing fast 2.5/10 Gigabit combo and upgrade your workspace! This switch can utilize the full potential of RouterOS v7: run VLANs, Jumbo frames, link aggregation, ACL rules, and so much more!

The world of networking is on the move. Even small offices are shifting from Gigabit connections to the lightning-fast realm of 2.5 Gigabit connectivity. With CRS310-8G+2S+IN, we aim to give you the tools to outpace your competition with a strong combination of eight 2.5 Gigabit Ethernet ports and two 10 Gigabit SFP+ ports in a compact, powerful package! Furthermore, these SFP+ cages support multiple data rates: 1G, 2.5G, and 10G. So you can use this switch as a 10x 2.5G switch, if needed. Classic MikroTik flexibility!
CRS310-8G+2S+IN
  • CRS310-8G+2S+IN
  • CRS310-8G+2S+IN
  • CRS310-8G+2S+IN

The amazing Marvell 98DX226S switch-chip and integrated dual-core ARM CPU can handle the full potential of RouterOS v7. Run VLANs, Jumbo frames, link aggregation, ACL rules, and so much more! You can even do some hardware offloaded Layer-3 routing.

There are multiple mounting options. You can easily install the CRS310-8G+2S+IN in a standard 19” rack using the provided rackmount ears. Another option is to get the RMK-2/10 accessory set, which allows you to mount two CRS310 units within the same 1U 19” rack space or mount it in a 10” rack. The choice is yours!

Specification

Specifications

  • Product codeCRS310-8G+2S+IN
  • Suggested price$219.00
  • ArchitectureARM 32bit
  • CPU98DX226S
  • CPU core count2
  • CPU nominal frequency800 MHz
  • Switch chip model98DX226S
  • Dimensions200 x 206,1 x 44
  • RouterOS license5
  • Operating SystemRouterOS v7 / SwitchOS
  • Size of RAM256 MB
  • Storage size32 MB
  • Storage typeFLASH
  • MTBFApproximately 200'000 hours at 25C
  • Tested ambient temperature-40°C to 60°C

Powering

  • Number of DC inputs1 (DC jack)
  • DC jack input Voltage18-57 V
  • Max power consumption34 W
  • Max power consumption without attachments21 W
  • Cooling type1 fan

Ethernet

  • Number of 2.5G Ethernet ports8

Fiber

  • SFP+ ports2

Peripherals

  • Number of USB ports1
  • USB Power ResetYes
  • USB slot typeUSB type A
  • Max USB current (A)1

Other

  • CPU temperature monitorYes
  • PCB temperature monitorYes

Certification & Approvals

  • CertificationCE, EAC, ROHS
  • IP20

Included parts24V 1.5A power adapterK-48 fastening setEarsNoteThe device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.
