cAP ax

cAP ax

$180.48 CAD

cAP ax

cAPGi-5HaxD2HaxD
$180.48 CAD
Shipping calculated at checkout.
Out of stock

The best-selling ceiling access point is back – stronger than ever! A new generation of wireless greatness for your office, hotel, mall, or any other setups in crowded areas. Modern quad-core CPU, 1GB of RAM, 2x Gigabit Ethernet ports, PoE, Gen 6 802.11ax wireless, PSU – included!

When it comes to wireless network in the office, you can’t afford to cut corners and risk inhibiting your team’s performance. You need excellent coverage throughout the premises. You need a device that can handle a large number of clients. You need a reliable, flexible, cost-effective solution: the cAP ax!

Both open office and cubicle layouts usually encounter a variety of network issues: signal gets absorbed, reflected, it becomes unstable. Mirrors, tinted glass, TVs, metal file cabinets – all sorts of things can get in the way. Our solution is simple, effective, and elegant: let your access point rise above all the obstacles! In other words, a ceiling access point is a great way to prevent signal loss in large, crowded areas with many obstacles.

There is another benefit to this form-factor: cAP ax remains hidden in plain sight, attracting less unwanted attention than a smoke sensor. Your clients, guests, or colleagues won’t even notice it. But they will definitely notice the blazing-fast wireless connection!

cAP ax

cAP ax features a modern quad-core CPU running at 1.8 GHz, NAND storage, and a gigabyte of RAM. Enough to harvest the full potential of the most powerful networking software on the market – RouterOS v7! Complex firewall rules, IPsec hardware encryption, Wireguard, BGP, advanced routing, or multiple remote work VPN tunnels – cAP ax can do it all!

Compared to the previous generation, cAP ax offers multiple enhanced authentication types: OWE, WPA3-PSK, WPA3- EAP, and 802.11r roaming.

cAP ax is also a great way to make your office network installation and maintenance so much easier, as it features PoE-in and PoE-out. That’s right – you can use cAP ax to power other devices, such as network switches, CCTV cameras, or even another cAP ax! And, speaking of easy office networks... Just a few clicks in our latest wifiwave2 CAPsMAN central management system - and you’re done setting up hundreds of cAP ax devices! You can use all sorts of MikroTik devices to run CAPsMAN effortlessly, for example - your main gateway.

Specification

Specifications

  • Product codecAPGi-5HaxD2HaxD
  • Suggested price$129.00
  • ArchitectureARM 64bit
  • CPUIPQ-6010
  • CPU core count4
  • CPU nominal frequencyauto (864 - 1800) MHz
  • CPU Threads count4
  • Switch chip modelIPQ-6010
  • RouterOS license4
  • Operating SystemRouterOS v7
  • Size of RAM1 GB
  • Storage size128 MB
  • Storage typeNAND
  • MTBFApproximately 200'000 hours at 25C
  • Tested ambient temperature-40°C to 70°C

Wireless capabilities

  • Wireless 2.4 GHz Max data rate574 Mbit/s
  • Wireless 2.4 GHz Number of chains2
  • Wireless 2.4 GHz standards802.11b/g/n/ax
  • Antenna gain dBi for 2.4 GHz6
  • Wireless 2.4 GHz chip modelQCN-5022
  • Wireless 2.4 GHz generationWi-Fi 6
  • Wireless 5 GHz Max data rate1200 Mbit/s
  • Wireless 5 GHz Number of chains2
  • Wireless 5 GHz standards802.11a/n/ac/ax
  • Antenna gain dBi for 5 GHz5.5
  • Wireless 5 GHz chip modelQCN-5052
  • Wireless 5 GHz generationWi-Fi 6
  • WiFi speedAX1800

Ethernet

  • 10/100/1000 Ethernet ports2
  • Number of 1G Ethernet ports with PoE-out1

Powering

  • Number of DC inputs2 (DC jack, PoE-IN)
  • DC jack input Voltage18-57 V
  • Max power consumption36 W
  • Max power consumption without attachments11 W
  • PoE in802.3af/at
  • Cooling typePassive
  • PoE in input Voltage18-57 V

PoE-out

  • PoE-out portsEther2
  • PoE outPassive PoE up to 57V
  • Low voltage PoE-Out current limit600 mA
  • High voltage PoE-Out current limit400 mA
  • Max total out (A)600 mA
  • Total output current0.4
  • Total output power19.2

Certification & Approvals

  • CertificationCE, FCC, IC, EAC, ROHS
  • IP20

Other

  • CPU temperature monitorYes
  • Mode buttonYes

Included parts48 V 0.95 A power adapterK-81 fastening setcAP ax ceiling bracketcAP ax ceiling mountGigabit PoE injectorNoteThe device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.
